Dust Free Belt-Driven Sliding Table Electric Cylinder
Sliding Table Series
LBC Series
Specification
| Model | LBC14 | LBC17 | |
 |  |
||
| Repeatability (mm) | ±0.04 | ||
| Motor (W) | 200 | 400 | |
| Lead (mm) | 40 | 40 | |
| Max. Speed (mm/s) | 2,000 | 2,000 | |
| Load | Horizontal (kg) | 25 | 45 |
| Vertical (kg) | - | - | |
| Effective Travel (mm) | 50 to 2,800 | 50 to 2,800 | |
